Corner and L-Shape Sofa Layout Planning

Left-Hand Versus Right-Hand Orientation

Orientation describes where the chaise or return sits when the sofa is viewed from the front. Left-hand models place the extension on the viewer's left, right-hand models place it on the right. The naming is easy to confuse, so retailers should publish a small floor diagram rather than rely on the words alone.

Orientation is chosen by the corner the sofa will occupy and by the walking route through the room. A sofa that blocks the only path to a balcony or doorway quickly becomes a complaint. Buyers can reduce confusion by stocking both orientations in the same cover, or by specifying a reversible connector that lets the dealer assemble the corner either way.

Chaise, Corner Module, or Both

An L-shape is built from two straight sections plus either a corner module or a chaise. A chaise combines the corner turn with an extended lounging seat, while a corner module turns the run and keeps seat depth uniform across the shape. Both appear in the same family, and both change the packing list.

Planning into a room means plotting the two overall lengths against the wall run, leaving clearance at the ends for legs and skirting, and checking that the lounging section does not sit across a doorway. Connector hardware keeps the modules aligned: brackets, plates or interlocking tabs transfer sideways load and stop the gap from opening when a sitter leans on the corner. Ask how the connectors are fixed, whether fixings are pre-drilled, and how the joint is hidden.

• Confirm the two overall lengths and the corner return width

• Check that both orientations are available in the chosen cover

• Review connector type, fixing method and pre-drilled points

• Confirm whether the corner module is a separate line item

Delivery Access for a Long Assembled Run

A sectional usually ships as several packages, which is an advantage: the largest single component, not the total length, determines whether the route works. Ask suppliers for the dimensions of the longest and widest piece and the weight of each carton, since upper floors without a lift depend on what two people can carry.

Where a room cannot be reached in one straight run, the assembly order should place the corner first and the straight sections after. Publish unpacked dimensions per module on the product page, and confirm spare connector parts are available for replacement orders.

Key Takeaways

• Describe orientation with a diagram, not words alone

• Chaise and corner module change the shape, packing list and price build-up

• Connector hardware should be pre-drilled, hidden and replaceable

• Plan access around the largest single component rather than total length
